ELOMP Lube Oil & Grease Manufacturing Plant — Phases I to IV
Complete tankage, vessels, piping and infrastructure for ENOC's lube oil and grease manufacturing plant across four phases — 75,000 inch-dia of piping, pipe racks, equipment erection, firefighting and a truck loading bay.
The scope
Nine vertical storage tanks of various sizes, sixteen base oil vessels, six additive vessels from Ø 5 m × 14 m to Ø 15 m × 18 m, fourteen homogenising vessels from Ø 2.7 m × 7.5 m to Ø 4.25 m × 9 m, compartmental tanks, utility piping, structural pipe racks and walkways, equipment erection, firefighting system, pump supply and a truck loading bay with civil, structural and E&I works.
Gallery
